How To Create A Rainwater Collection System & 10 Homemade Solutions

Sharing is caring!

Rainwater harvesting represents an ancient practice revitalized by modern sustainability efforts. By capturing rainwater, individuals can reduce their dependence on municipal water systems, lower their utility bills, and contribute positively to the environment.

This article explores the construction of a basic rainwater catching system and introduces ten homemade solutions that can be implemented by anyone looking to optimize their water usage.

Fundamentals of Rainwater Catching

Rainwater catching systems collect and store rainwater from surfaces like rooftops. The harvested water can then be used for various purposes such as irrigation, washing, and even drinking, if properly filtered. A standard system comprises several components:

Catchment Area: Typically the roof, which acts as the primary surface for water collection.

Conveyance System: Gutters and downspouts channel the water from the roof to the storage area.

Storage Containers: Tanks or barrels where the collected water is held.

Filtration System: Necessary for purifying the water, especially if it will be used indoors or for drinking.

Distribution System: Methods used to transport the stored water to where it is needed.

Understanding these components helps in designing a system that suits specific needs and complies with local regulations.

Plan Your Rainwater Catching System

Planning is crucial for creating an effective rainwater harvesting setup. Start by estimating the potential volume of rainwater your roof can collect.

This calculation involves measuring your roof’s surface area and multiplying it by the rainfall rate in your area.

Also, assess your household’s typical water usage to determine the capacity needed for your storage containers.

Select a location for your rainwater system that is near both the downspout and the areas where you will use the water most frequently, like gardens or washing stations.

Remember to check local laws regarding rainwater collection, as some regions have specific requirements or restrictions.

List of Tools and Materials

To construct a basic rainwater catching system, you will need:

  • PVC gutters and downspouts
  • Storage tanks or barrels
  • PVC pipes and fittings
  • Filter system (can be as simple as mesh screens to more complex filtration units)
  • Tools for installation (drill, saw, wrenches, etc.)
  • Sealants and brackets for securing system components

Consider using recycled materials to keep costs down. For instance, repurposed food-grade barrels can serve as effective storage containers.

Step-by-Step Guide to Building a Basic Rainwater Catching System

Constructing a rainwater catching system involves several straightforward steps:

Step 1: Setup of the Catchment Area

Begin by preparing your roof to serve as the catchment area. Clean the roof and gutters thoroughly to remove debris that could contaminate the water or clog the conveyance system.

Step 2: Installation of Gutters and Downspouts

If your home doesn’t already have them, install gutters along the edges of your roof. Ensure they slope slightly towards the downspouts to prevent water pooling. Attach downspouts that direct the water from the gutters to your storage area.

Step 3: Connection to Storage Tanks

Position your storage tanks or barrels near the downspouts. Use PVC pipes or flexible tubing to channel water from the downspouts into the tanks. Include overflow pipes that direct excess water away from your home’s foundation.

Step 4: Implementation of Filtration

Install filters at the entrance of your storage tanks to keep out debris and insects. These can range from simple mesh screens to more complex systems depending on your purification needs.

Step 5: Establishment of the Distribution System

Finally, set up a distribution system to move water from the storage tanks to where it will be used. This can be a gravity-fed system for gardens or a more elaborate setup with pumps for household use.

10 Homemade Rainwater Catching Solutions

Each of these solutions can be tailored to fit different needs and capacities, allowing for flexibility and creativity in your approach to rainwater harvesting.

1. Simple Barrel System

Start with the basics by using a 55-gallon drum or barrel. Place it directly underneath a downspout to catch rain directly from your gutters. This solution is cost-effective and easy to implement for beginners.

2. Connected Barrel System for Increased Capacity

To increase your storage capacity, connect multiple barrels with PVC pipes or hoses. Use valves to control the flow between barrels, ensuring they fill evenly and maintain balance.

3. Underground Storage Solution

For those with limited space or aesthetic concerns, consider burying your storage tanks. This not only hides the tanks but also keeps the water cooler and reduces the likelihood of algae growth.

4. Dry System Setup

A dry system involves pipes that empty directly into the storage tank after each rain event, leaving the pipes dry between rains. This setup is simpler and typically requires less maintenance than wet systems.

5. Wet System Setup

In a wet system, the pipes remain filled with water between rains, which can be useful in climates where evaporation is a concern. This setup requires careful planning to prevent freezing and blockages.

6. DIY First Flush Diverter

Build your own first flush diverter to improve water quality. This device diverts the first few gallons of rain—which contain the majority of the debris and contaminants—away from your storage tank.

7. Using IBC Totes for Storage

Intermediate Bulk Container (IBC) totes are large containers that can hold several hundred gallons of water.

These are excellent for more substantial rainwater catching systems and can be connected for expanded storage.

8. Green Roof Water Catchment

If you have a flat roof, consider a green roof system where vegetation is planted directly on your roof.

This not only helps with insulation and biodiversity but also pre-filters the water before it reaches your storage system.

9. Portable Rainwater Harvester

For those who need flexibility, a portable rainwater harvester can be a great solution. Use a rollable tank or a foldable container to collect rainwater at various points around your property.

10. Incorporating Rainwater Catching into Landscaping

Integrate your rainwater system with your landscaping by designing features like rain gardens or permeable pathways that utilize runoff effectively and enhance the beauty of your outdoor space.

Maintenance and Upkeep

Regular maintenance is essential to ensure your rainwater catching system operates efficiently. Clean your gutters, inspect and clear filters, and check for leaks regularly. Keep an eye on your system during heavy rains to ensure everything is functioning properly.

Enhancement of Efficiency and Sustainability

To make your system even more efficient, consider adding solar-powered pumps to distribute the water or connect your system to an irrigation setup for automated garden watering.

Complementing your rainwater harvesting with other sustainable practices like composting and solar energy can lead to a significantly greener lifestyle.

By adopting one or more of these homemade rainwater catching solutions, you can significantly reduce your environmental footprint while saving money on water bills. Customize your system to fit your specific needs, and enjoy the benefits of sustainable living.
